High Precision Weights Class E2
High Precision Weights Class E2 (200g to 1mg)
Adjustment, test, verification and calibration weights for class I precision balances. For quality assurance of scales with a number of steps < 1.000.000. For weighing or comparison measurements on scales of class l or on mass comparators. For calibration and verification of weights of classes F1 and F2 according to OIML R111.
| 200g to 1mg |
TOLRENCES (in mg+/-) | |
| Nominal value | Class E2 | |
| 200 g | 0.3 | |
| 100 g | 0.16 | |
| 50 g | 0.10 | |
| 20 g | 0.08 | |
| 10 g | 0.06 | |
| 5 g | 0.05 | |
| 2 g | 0.04 | |
| 1 g | 0.03 | |
| 500 mg | 0.025 | |
| 200 mg | 0.020 | |
| 100 mg | 0.016 | |
| 50 mg | 0.012 | |
| 20 mg | 0.010 | |
| 10 mg | 0.008 | |
| 5 mg | 0.006 | |
| 2 mg | 0.006 | |
| 1 mg | 0.006 | |
High Precision Weights Class E2 (50kg to 500g)
| 50kg to 500g |
TOLRENCES (in mg) | |
| Nominal value | Class E2 | |
| 50kg | 25.0 | |
| 20kg | 10.0 | |
| 10kg | 5.0 | |
| 5kg | 2.5 | |
| 2kg | 1.0 | |
| 1kg | 0.5 | |
| 500g | 0.25 | |
Features and Specifications
Material：Austenitic Stainless steel Grade 316
Process：Mirror/Mechanical Polishing
Style: Cylindrical
Standard: OIML
Application
Applicable Place: Laboratories, Pharmaceutical Factories, Defence, Space & Aeronautical Labs, Scales Factories, etc.
Applications: Calibration for scales, balances or other weighing products.
Advantages
Stainless steel has the characteristics of resistance to weak corrosive media such as air, steam, water and chemical etching media such as acid, alkali and salt. The weight made with this material is also resistant to corrosion by corrosive media such as air, steam, water, and chemical etching media such as acid, alkali, and salt. It extends service life and improves the accuracy of weights.
