Mass Standards E1
Mass Standards Class E1 (200g to 1mg)
Adjustment, testing and calibration instrument for quality assurance of scales with a number of steps > 1.000.000 for calibration and verification of class E2 weights according to OIML R111. For high-precision weighing or comparative measurements on mass comparators.
| 200g to 1mg | TOLRENCES (in mg+/-) | |
| Nominal value | Class E1 | |
| 200 g | 0.10 | |
| 100 g | 0.05 | |
| 50 g | 0.03 | |
| 20 g | 0.025 | |
| 10 g | 0.020 | |
| 5 g | 0.016 | |
| 2 g | 0.012 | |
| 1 g | 0.010 | |
| 500 mg | 0.008 | |
| 200 mg | 0.006 | |
| 100 mg | 0.005 | |
| 50 mg | 0.004 | |
| 20 mg | 0.003 | |
| 10 mg | 0.003 | |
| 5 mg | 0.003 | |
| 2 mg | 0.003 | |
| 1 mg | 0.003 | |
Mass Standard Class E1 (50kg to 500g)
| 50kg to 500g |
TOLRENCES (in mg) | |
| Nominal value | Class E1 | |
| 50kg | 25.0 | |
| 20kg | 10.0 | |
| 10kg | 5.0 | |
| 5kg | 2.5 | |
| 2kg | 1.0 | |
| 1kg | 0.5 | |
| 500g | 0.25 | |
Features and Specifications
Material：Austenitic Stainless steel Grade 316
Process：Mirror/Mechanical Polishing
Style: Cylindrical
Standard: OIML
Application
Applicable Place: Laboratories, Pharmaceutical Factories, Defence, Space & Aeronautical Labs, Scales Factories, etc.
Applications: Calibration for scales, balances or other weighing products.
Advantages
Stainless steel has the characteristics of resistance to weak corrosive media such as air, steam, water and chemical etching media such as acid, alkali and salt. The weight made with this material is also resistant to corrosion by corrosive media such as air, steam, water, and chemical etching media such as acid, alkali, and salt. It extends service life and improves the accuracy of weights.
